Perforated Rack Decking

Description

Ideal for storing furniture, carpet, record files or products that require a uniform support.

Fire protection friendly with 50% open design. Designed for pallet rack beam with 42″ deep racking. The bright galvanized finish makes the 22 gauge steel rack appear more industrial. Fits 1-1/2.” beam offset. The top hats are 3-1/2″ wide with top slotted holes 1-1/4″ x 2-1/2″ and the valleys are 2-1/2″ wide with slotted holes 1″ x 3″. Custom sizes available, contact factory.

Open Area Rack Decking
Model	Image	PDF	Beam Length	Frame Depth	Span	Capacity (lbs)	Wt. (lbs)
PCH-96			96″	42″	38 1/2″	3,780	62
PCH-108			108″	42″	38 1/2″	3,780	72
PCH-120			120″	42″	38 1/2″	3,780	82

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
