Description
Digging Depth 8 Feet
Output Rating 23.6HP
Operating Weight 5,919 LBS.
The V5 Mini Excavator series not only has zero tail swing, but its high-powered digging force is increased by 10%, and the 4-pump system is quick to respond, making this the ultimate mini excavator.
Comfortable and easy-to-use, the V5 mini excavators are also fuel efficient and easy to maintain. With an auto-parking brake and a neutral engine-start, the V5 mini excavators are proactive in error-prevention.
Performance (Key Specs)
| Bucket Capacity | 2.8ft3 |
| Bucket Width | 18″ |
| Operating Width | 5,919 lbs |
| Transport Weight | 5,512 lbs. |
| Swing Speed | 9 rpm |
| Travel Speed (Low/ High) | 1.5 mph / 2.7 mph |
| Gradeability | 30° |
| Ground Pressure | 4.5 psi |
| Bucket Digging Force | 4,721 lbs |
Engine
| Model | Kubota D1305-E4B |
| Output Rating | 23.6 hp / 2,400rpm |
| Fuel Tank Capacity | 11 gallons |
Boom Swing System
| Type | Offset Boom w/ Hydraulic Cyl. |
| Swing Angle (L / R) | 50° / 80° |
Hydraulic System
| Total Hydraulic System Flow | 20 gpm |
| Max Auxiliary Hydraulic Flow | 11 gpm |
Dozer Blade
| Size | 5’ 1” x 1’ 3” |
| Lift Above / Drop Below Ground | 1’ 2” / 1’ 5” |
