Description
Hand Carry Air Compressors
Model JC10PLUS – a super-quiet oilless air compressor – is the follow-up to our wildly popular JC10. The JC10PLUS features a host of improved features including a larger tank, sturdier roll-cage, integrated cord wrap and upward-facing gauges. The two-cylinder pump is powered by a 1700 RPM low-amp draw motor for maximum efficiency.
SPECIFICATIONS
| HORSE POWER | 1 HP |
| CFM DISPLACED | 4.1 CFM |
| CFM DELIVERED | 2.4 CFM @ 90 PSI |
| PUMP/MOTOR RPM | 1700 |
| OVERLOAD PROTECTION | Yes (Automatic) |
| LUBRICATION TYPE | Oil-Less |
| REED VALVE SYSTEM | Yes (Standard) |
| NUMBER OF CYLINDERS | 2 |
| TANK CAPACITY | 2.5 Gallons |
| L X W X H | 16.5″ x 16.5″ x 14″ |
| DECIBEL RATING | 60 dBA |
| SHIPPING WEIGHT | 50 lb. |
| SHIPPING DIMENSIONS (L X W X H) | 17″ x 17″ x 15″ |
DOCUMENTS
JC10PLUS Spec Sheet
JC10PLUS Schematic
JC10PLUS Owner’s Manual
