Description
Hinge & Sliding Tilting Tables
Hinge Tilt Model: EHTT
The Hinge Tilt Table offers the rugged durability of the standard Efficiency Master l of tilters, plus they offer an extra low platform height. Tilting capabilities up to 45 degrees and a 12″ lip without side gussets allows for loading and unloading on three sides. Standard platform is 48″ wide 47-3/4″ long with a 4,000 lb. capacity. Other sizes and capacities are available for this heavy-duty tilt table. The EHTT features a 2 HP 460V AC power unit with a 24-volt two button handheld pendant control, other voltages available. A pressure plated pump coupled to an application specific manifold features counterbalanced valves and modulated flow control for maximum efficiency.
Sliding Tilt Model: EHTT-L
The Sliding Tilt Table has the same features as the hinge tilt table and incorporates a patented sliding link-tilt design for maximum stability while occupying minimum space. As the heavy-duty table is tilted, the front edge of the container moves away from the operator. The center-of-gravity of the load remains closer to the center of the frame minimizing the possibility of the unit tipping. Standard size is 48″ wide by 47-3/4″ long with a 4,000 lb. capacity. Features include: 8″ lowered height, 45-degree tilt and a 12″ lip. Three sided access provides quick loading and unloading. Other sizes and capacities are available. The EHTT-L features a 2HP 460V AC power unit with a 24 Volt two button handheld pendant control for tilt functions. A pressure plated pump couples to an application specific manifold featuring counterbalanced valves provide efficient, modulated flow controls.
EHTT – Stationary with four (4) lag down points.
EHTT-L – Base includes 7-1/2″ W x 2-1/2″ H usable fork pockets on 28″ centers for portability.
All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
| Sliding & Hinged Tilt Tables | ||||||||
| Model | Image | PDF’s | Design | Platform Size (WxL) |
Capacity (lbs.) |
Lowered Height |
Degree Of Tilt |
Wt. (lbs.) |
| EHTT |  |
   |
Hinge | 48″x47-3/4″ | 4,000 | 10″ | 45 | 780 |
| EHTT-L |  |
|
Sliding | 48″x47-3/4″ | 4,000 | 8″ | 45 | 812 |
| Three Sided Accordian Skirt Available, Contact Factory | ||||||||
KEY: = Approval Drawing —
= Warranty — = Testing Certificate
