Description
The wood/metal vertical band saws are two saws in one. Specially designed to effectively cut a variety of materials including wood, plastic, composites, ferrous and non-ferrous metals.
- Unitized welded steel frame construction
- Cast blade wheels
- Large ground cast iron work table that tilts up to 45°
- Adjustable precision bearing blade guides
- Hinged wheel covers and convenient blade tensioning wheel for easy accessibility and fast blade changing and adjustments
- 4″ dust port
- Rip fence
- Miter gauge
- Chip blower
- Chip chute
- Extra wide speed range
- 15″ comes with one 1/2″ – 14 TPI metal blade, and one 1/2″ – 6 TPI wood blade
- 18″ comes with one 3/4″ – 14 TPI metal blade, and one 3/4″ – 6 TPI wood blade
| Band Saw Type | Vertical |
| Blade Length | 114 in |
| Blade Width | 1/8″ to 3/4″ |
| Blade Thickness | 0.035 in |
| Cold Saw and Band Saw Saw Type | Manual |
| Coolant | Air |
| Country of Origin | TW |
| Cutting Capacity | 254 mm / 10 in round |
| Cutting Capacity Miter | 45° |
| Frequency of Use | Intermittent Use, Light Production (Less than 25% of work day) |
| Manual Horiz. Band Saw Type | Miter with vise |
| Material to be Cut | Ferrous Metals, Non-Ferrous Metals, Composites, Plastics, Wood |
| Miter Capacity | 45° |
| Model Number | 83115 |
| Motor HP | 1 |
| Optional Accessories | Replacement Blade for 9683115 9683325 Bi-Metal, 1/2″ x 0.035″ x 10-14 TPI; 9683326 Carbon, 1/2″ x 0.032″ x 4 TPI; Replacement Blade for 9683118 9683327 Bi-Metal, 3/4″ x 0.035″ x 10-14 TPI; 9683328 Carbon, 3/4″ x 0.032″ x 6 TPI |
| Overall Dimensions (LxWxH) | 25″ x 27″ x 78″ |
| Phase | Single |
| Sawing Type | Vertical Band Saws |
| Table Dimensions | 15 x 15 in |
| Throat Capacity | 15″ |
| Type of Cutting | Angle/Miter, Contour, Cutting-Off, Pattern/Cutting Out/Notching, Ripping, Single Piece, Stacking, Straight |
| Voltage | 115/230 |
| Warranty | 3 Year |
| Wood Cutting Saw Type | Vertical |
| UPC | 726896831152 |
| Unit of Measure | Each |
| Product Height (in) | 76 |
| Product Length (in) | 24 |
| Product Width (in) | 26 |
| Product Weight (lbs) | 346 |
